SW2036 Medium to large size video wall ,36 display outputs /Able to capture maximum 32 HD video inputs

Features

SW2036 offers up to 36 display outputs and is able to capture maximum 32 HD video inputs or 128 composite video inputs. It is the most cost effective video wall controller on market for a medium to large size video wall application.

- Advanced CrossBar technology
- Robust FPGA video data process technology
- No PC vulnerabilities
- 1 to 144 display outputs
- Multi output option: DVI-I (Digital & Analog), SDI, HDBaseT, Optical Fibre
- 1-256 1080p IP camera inputs capture
- 1-128 HD DVI/HDMI/RGB inputs capture
- 1-512 composite video inputs capture
- Multi input option: DVI-D, HDMI, VGA, YPbPr, CVBS, SDI, HDBaseT, Optical Fibre, IP streaming
- MVWS( Multi Video Walls Support) technology
- Low power consumption
- Fast start up within 5 seconds, Low capture & display latency
- HDCP support for DVI/HDMI
- Support 4K input capture
- Support IP signal decode and capture
