Description
Powered by the latest generation of Intel® Celeron® processor J1900 (formerly codenamed “Bay Trail-D”), NIFE 200P2 presents intelligent PC-based controller and IoT gateway for factory automation. NIFE 200P2/P2E supports up to 8G DDR3L memory and have several options on storage devices like SD, mSATA, HDD and SSD. The NIFE 200P2/P2E support operating temperature from -5 up to 55 degree C with typical DC input 24V ±20% range. The
NIFE 200P2 has high integration ability with optional mini-PCIe module and 2 x COM ports, which makes it a reliable connection with devices in factory automation applications (with optional PROFIBUS, PROFINET, DeviceNET, EtherCAT, EtherNet/IP, CANopen, SERCOSIII master module), IoT applications (with optional GbE LAN, Wi-Fi, 3.5G/4G LTE module) and communication applications (with optional GPIO, RS232/422/485). NIFE 200P2 is definitely the top choice for M2M intelligent system as a factory automation controller and gateway
Features
- Onboard Intel® Celeron® processor J1900 Quad Core 2.0GHz
- RAM 4GB DDR3L 1866 SO-DIMM
- SSD128GB 2.5 SATA3
- Dual independent display from DP and DVI-I
- 2 x Intel® I210AT GbE LAN ports support WoL, Teaming and PXE
- 3 x USB 2.0 & 1 x USB 3.0
- 2 x RS232/422/485
- 2 x Mini-PCIe socket for optional Wi-Fi/3.5G/4G LTE/Fieldbus modules
- TOP access SD card socket
- Support -5 ~ 55 degree C operating temperature
- Typical 24V DC input with +/-20% range, with reverse polarity protection
**ไม่รวม Windows
