SW8036 Video wall controller designed for large size 4K video wall ,Support maximum 36 4K displays

Features

 SW8036 is a video wall controller designed for large size 4K video wall with hundreds of video captures. With its ability to support maximum 36 4K displays in one video wall, it is an ideal video wall system for extra large digital signage, surveillance, command & control rooms and other video wall applications.

- 1 to 36 4K display outputs
- Eight-window overlay mode
- Multi output option: HDMI, DL-DVI
- 1-128 HD DVI/HDMI/RGB inputs capture
- 1-36 4K video inputs capture
- No PC vulnerabilities
- Input signal preview
- Advanced PCI Express and Crossbar technology
- Robust FPGA video data process technology
- Multi input option: DVI-D, HDMI, VGA, YPbPr, CVBS, SDI, HDBaseT, Optical Fibre, DisplayPort, IP streaming
- MVWS( Multi Video Walls Support) technology
- Low power consumption
- Fast start up within 5 seconds, Low capture & display latency
- HDCP support for DVI/HDMI
- Support IP signal decode and capture
