Description
The LC-221 is an easy-to-use dimming ballast control module that requires no specialist skills to install and operate. It provides two methods of controlling the brightness of fluorescent lamps via a dimmer, either via digital input or a host controller. The digital input can directly control the light value from 10% to 100% luminous fl ux in sequence, without requiring a remote host controller. 4 kV ESD protection and 2500 VDC intra-module isolation are also provided. When required, communication with the LC-221 is programmable based on the Modbus RTU protocol, and an added benefit is that different addresses can be set for Modbus RTU communication via hardware configuration.
Features
- Power Relay Output
- Isolated AC Digital Input
- Isolated Analog Output For Control Dimming Ballast
- Supports Modbus RTU and DCON Protocols
- 2500 VDC Intra-Module Isolation
- +/-4 kV ESD Protection
- Tiny form-factor with easy screw mounting
Term and Condition
รับประกันสินค้า : 1 Year
