PFN-2042 PROFINET I/O Module (Isolated 16-ch DO)

Features

• Protocol: PROFINET IO Device
• PROFINET Conformance Class B and RT Class 1
• Cyclic Time: 1ms (min)
• Generic GSDML File Provided (Version 2.25)
• Do load voltage: +3.5 ~ +50 VDC
• Do load current: 700 mA/Channel (max.)
• Provide short-circuit protection on DO channels
• 4 kV Contact ESD protection for any terminal
