GW-7243D-G DeviceNet Slave to Modbus TCP/RTU/ASCII Master Gateway

ICP DASSKU: GW-7243D-G
No reviews

Price:
Sale price18,480.00 ฿

Shipping calculated at checkout

Stock:
Re-stocking soon

Description

Features

DeviceNet Features
- Comply with DeviceNet specification Volume I/II, Release 2.0
- "Group 2 Only Server” DeviceNet subscriber
- Support Offline Connection Set and Device Shutdown Message
- Explicit & I/O length: 240 bytes max.
- Connection supported: one “Explicit Connection”, one “Polled Command/Response” connection
Modbus RTU Features
- User can select the Modbus RTU/ASCII protocol for each COM port
- Maximum support 10 Modbus RTU/ASCII commands for each COM port
- Maximum support 1920 channels DI/O for a Modbus RTU/ASCII command
- Maximum support 120 channels AI/O for a Modbus RTU/ASCII command
- Maximum support 2048 channels DI,2048 channels DO,1024 channels AI and 1024 channels AO for each COM port
Modbus TCP Features
- Maximum support 4 Modbus TCP devices
- Maximum support 5 Modbus TCP commands for each Modbus TCP device
- Maximum support 1920 channels DI/O for a Modbus TCP command
- Maximum support 120 channels AI/O for a Modbus TCP command
- Maximum support 2048 channels DI,2048 channels DO,1024 channels AI and 1024 channels AO for each Modbus TCP device

Term and Condition

รับประกันสินค้า : 1 Year

Download

Datasheet
Download
