GW-7553-CPM PROFIBUS to CANopen Gateway

Features

- Protocol & Hierarchy : DP-V0 Slave
- Transmission Rate Setting : detected automatically
- Max Input Data Length : 240 Bytes
- Max Output Data Length : 240 Bytes
- PROFIBUS Address Setting : 0~126 set by DIP switch
- Supports CANopen Standard : CiA CANopen Standard DS-301 v4.02
- Supports CANopen Consumer protocol : Node Guarding and Heartbeat Consumer protocol
- Number of CANopen Commands : Support 110 CANopen SDO/PDO commands
- Network Isolation Protection : 2500 Vrms High Speed iCoupler
- DC Isolation Protection : 3000VDC on PROFIBUS side
