SW2072A Large size video wall ,support up to 72 display outputs / capture maximum 64 HD

Features

SW2072A is able to support up to 72 display outputs and capture maximum 64 HD video inputs or 256 composite video inputs simultaneously within one chassis. It is the perfect choice for large size video wall application.

- Advanced CrossBar technology
- Robust FPGA video data process technology
- No PC vulnerabilities
- 1 to 144 display outputs
- Multi output option: DVI-I (Digital & Analog), SDI, HDBaseT, Optical Fibre
- 1-256 1080p IP camera inputs capture
- 1-128 HD DVI/HDMI/RGB inputs capture
- 1-512 composite video inputs capture
- Multi input option: DVI-D, HDMI, VGA, YPbPr, CVBS, SDI, HDBaseT, Optical Fibre, IP streaming
- MVWS( Multi Video Walls Support) technology
- Low power consumption
- Fast start up within 5 seconds, Low capture & display latency
- HDCP support for DVI/HDMI
- Support 4K input capture
- Support IP signal decode and capture
