SW4018 Displays ranging up to 18 screens, Able to capture 52 HD inputs

Features

SW4018 is designed for a flexible wall sized display wall with displays ranging up to 18 screens, moreover it is able to capture 52 HD inputs and display them all simultaneously. It is an ideal video wall system for small to medium command & control rooms.

- Advanced Crossbar technology
- Robust FPGA video data process technology
- No PC vulnerabilities
- Input signal preview
- Four-window overlay mode
- 1 to 72 display outputs
- Multi output option: DVI-I (Digital & Analog), SDI, HDBaseT, Optical Fibre
- 1-256 1080p IP camera inputs capture
- 1-128 HD DVI/HDMI/RGB inputs capture
- 1-512 composite video inputs capture
- Multi input option: DVI-D, HDMI, VGA, YPbPr, CVBS, SDI, HDBaseT, Optical Fibre, IP streaming
- MVWS( Multi Video Walls Support) technology
- Low power consumption
- Fast start up within 5 seconds, Low capture & display latency
- HDCP support for DVI/HDMI
- Support 4K input capture
- Support IP signal decode and capture
