SWP16 CHASSIS 16U, 156 INPUT/40 OUTPUT ,Video wall controllers are the most Advanced solution

Features

- CHASSIS : 16U
- DIMENSION(MM)/(W*D*H) : 482*380*708
- MAX INPUT(HD) : 156
- MAX OUTPUT(HD) : 40

- Advanced PCI Express technology ,Advanced Crossbar technology
- Supports 4K@60fps input and output
- Supports digital and analog audio
- Supports KVM , Supports scrolling text
- Supports input signal preview , Supports local video wall mapping
- Supports system live monitoring , Supports 4K IP streaming decoding
- Supports OSD on output windows
- Multi clients support
- User access control
- Robust FPGA video data process technology
- No PC vulnerabilities
- Multi output option: DVI-I (Digital & Analog), HDMI, HDBaseT, Optical Fibre
- Low power consumption , Multi video walls support in one system
- Multi input option: DVI-D, HDMI, VGA, SD, SDI, HDBaseT, Optical Fibre
- HDCP compliant
- Supports customised EDID on inputs and outputs
- Supports over 1000 pre-set layouts
- Layouts looping ability
