ES106 Environmental monitoring Sensor

Features

ES106 is an intergraded device and designed for all types of environmental monitoring. It can be used to detect multiple parameters of temperature, humidity, PM2.5, PM10, wind speed and wind direction in the environment. Each parameter is independent and high sensitivity, users can freely integrate monitoring parameters.

ES100 has the characteristics of high precision and good stability, which is suitable for various environmental monitoring.

Intergraded Device

• Intergraded multiple sensorsCentral management by sharing a signal output
• Support Industrial Modbus RTU protocol, RS485

Outdoor Protective Enclosure

• Prevent direct ultraviolet radiation to the sensors
• Avoid rapid aging of sensors under harsh environmental conditions such as strong winds, rain, and snow
• The sensor parts are ventilated for truly sensing the changes in external detection parameters

Flexible Design

• Customized Shutter Height: Single or multiple parameters both can use small shutter, small size, light weight and easy to install
• Customized Monitoring parameters: Each parameter is an independent and high sensitivity, users can freely integrate monitoring parameters

Optional IoT Router and Cloud Platform - ThingsMaster

• Support Modbus to connect optional NBIoT Gateway WR222 for one or many sensors
• Real-time online monitoring, analysis, reporting
• Remote cloud security and visual management
