Description
Features
- Easy firmware update via Ethernet
- Removable terminal block connector
- Tiny form-factor and low power consumption
- Ethernet Protocol: EtherNet/IP adapter
- Maximum number of connections for Explicit Messages: 6
- Maximum number of connections for Implicit Messages: 1
- Supported I/O connection methods:
Transport and trigger: Exclusive-Owner, Cyclic
Originator to Target Type: POINT2POINT
Target to Originator Type: POINT2POINT, MULTICAST
- EtherNet/IP Input/Output command data size: maximum 500 bytes
- Modbus Protocol: Modbus RTU Master
- Maximum support 30 Modbus RTU commands
- Maximum support 10 Modbus TCP servers
- Maximum support 8 Modbus commands for each one Modbus TCP server
- Supported Modbus RTU Function Codes: 01,02,03,04,0F,10
- Maximum data size of one Modbus command: 240 bytes
Term and Condition
รับประกันสินค้า : 1 Year
